中文版APG-858 Epoxy-resin automatic pressure gelation hydraulic moulding machine
Main Technical Parameters
| Model | APG-858 |
| Clamping plate | 800*600mm |
| Mould clamping force | 125KN |
| Mould clamping speed | 2m/min |
| Max mould clamping distance | 800mm |
| Min mould clamping distance | 150mm |
| Power of hydraulic station | 4KW |
| Inclination angle of complete machine | Vertical 5°Horizontal 5° |
| Weight of complete machine | 6200KG |
| Outline dimension | 5400*1200*3020mm |
